OKM GEOSEEKER

(0 Customer reviews)

KWD 3061

OKM GEOSEEKER

WATER DETECTOR AND CAVITY DETECTOR UP TO 250 METERS (820 FT) DEPTH

Depth 250 Meters
Industry German
Warranty 5 Years
Company OKM
Description

Description

OKM GEOSEEKER

WATER DETECTOR AND CAVITY DETECTOR UP TO 250 METERS (820 FT) DEPTH

Are you looking for underground water resources or hidden cavities up to depths of 250 meters (820 ft)? The GeoSeeker is a professional geoelectrical water detector and cavity detector that measures the ground resistivity and visualizes its scan data in incredible 3D graphics. It is a very mobile and easy-to-operate geoelectrical detector designed and manufactured in Germany.

The GeoSeeker utilizes a geoelectrical measurement procedure based on Schlumberger to read the apparent resistivity of the ground. Based on that ground resistivity the detector is capable to locate underground water deposits, water-bearing gravel, and groundwater levels as well as cavities like caves, tunnels, chambers, and the like. Thus, the geophysical detector can be deployed as a water finder or cavity detector at the same time.

GEOSEEKER SCAN MODES

The GeoSeeker’s hardware components are completely controlled by a modern Android Tablet PC. All commands and measurement results are transferred wireless via Wi-Fi. Using the pre-installed software application you simply select one of three supported scan modes:

Active Scan (Accurate)

Active Scan (Quick)

Passive Scan

Active Scan (Accurate)

While using this scan mode the GeoSeeker utilizes two electrodes to inject electrical power into the underground soil. Two additional electrodes are measuring the potential difference (fall of voltage) at specific scan points to calculate the final resistivity value. This mode is used to detect underground water deposits, hidden caves, or even impervious layers and barriers within the underground soil. Inactive scans, you will be able to define a specific depth range in that you are going to conduct your measurement. So you will define a starting and ending depth between 5 meters (16 feet) and 250 meters (820 feet).

Active Scan (Quick)

This scan mode is a quick version of the accurate scan. It is also injecting electrical current into the underground and measuring the potential difference (fall of voltage) to calculate the resistivity of the ground.

Passive Scan

While using this scan mode the GeoSeeker only utilizes two electrodes to read the naturally occurring voltage of the underground (no electrical power is injected into the underground). This mode is used to detect underground flowing water only.

FOR MORE INFO ON OKM GEOSEEKER – WATCH THE OKM GEOSEEKER VIDEO HERE!

FOR QUICK SETUP, WATCH HERE!

GEOSEEKER SOFTWARE

The GeoSeeker’s software application is providing simple step-by-step instructions to assist you in completing the measurement. You simply follow these pictured instructions until your measurement has been finished. After completing the measurement a graphical 3d representation of the measure values is created and displayed on the screen of your Tablet PC. Some color adjustment options are provided to optimize the graphical 3d visualization of your underground water deposits, water-bearing gravel, and groundwater level (shown in bluish colors) as well as cavities, caves, tunnels, chambers, or impervious layers (shown in reddish colors).

GEOSEEKER LANGUAGES

The graphical user interface of the water detector GeoSeeker is available in the following languages:

Deutsch

English

Français

Español

Italiano

عربي

Ελληνικά

Türkçe

中文

Pусский

Nederlands

فارسی

GEOSEEKER TRANSPORTATION

The GeoSeeker’s hardware is built-in into a waterproof and shock-resistance Peli case. So your geoelectrical equipment is well packed and always ready for transportation.

FOR MORE INFO ON OKM GEOSEEKER – WATCH THE OKM GEOSEEKER VIDEO HERE!

FOR QUICK SETUP, WATCH HERE!

VOLTAGE CABLE DRUMS (Ø 120 MM)

Dimensions (H x W x D): 360 x 290 x 200 mm

Weight: 6.5 kg

Cable Length: 255 m

Markers: 15

POWER CABLE DRUMS (Ø 290 MM)

Dimensions (H x W x D): 120 x 120 x 45 mm

Weight: 0.65 kg

Cable Length: 26 m

Markers: 25

CONTROLLER (RECEIVING UNIT)

Dimensions (H x W x D): 130 x 270 x 110 mm

Weight: 0.6 kg / 2.1 kg (with mounted cable reels and batteries)

Sample Rate: 4096 Hz (64 times oversampling of a 512 samples mean value)

Operating Time: Min. 16 hours (charged batteries)

Charging Time: 3 h / max. 5 h (empty batteries)

CPU: 80 MHz Cortex M3

ADC: 16 bit

Communication with Tablet PC: WLAN-Accesspoint, 2.4 GHz band, channel 6, WPA2

Communication with Power Box: 2.4 GHz band, on-demand, proprietary

Effective Range: –1400 to +1400 mV

Measurement Period Per Scan Point: Min. 16 seconds

Power Supply (8 AA batteries): 8 – 14 V DC

Input (For Charger): 12 V DC / 1.5 A

Input Resistance (Static): Approx. 12 MΩ

POWER BOX (SENDING UNIT)

Dimensions (H x W x D): 230 x 550 x 360 mm

Weight: 15.8 kg / 18 kg (with mounted Electrodes)

Operating Time: 100 h (min. Power) / 40 h (average Power) / 8 h (max. Power)

Charging Time: Max. 8 hours

Output: Max. 390 V / 0.5 A / 20 W

Communication With Controller: 2.4 GHz band, on-demand, proprietary

Input (For Charger): 24 V DC / 2 A

Internal Power Supply: Lead Acid Battery (2 x 12 V, 10 Ah)

ELECTRODES

Dimensions (H x W x D): 440 x 120 x 35 mm

Weight: 0.52 kg



Parts & Content

صندوق للجهاز وحدة التحكم بطارية AA 1.5 V شاحن خاص بلوحة التحكم شاحن لصندوق الطاقة شاحن ومحول للسفر والتنقل كمبيوتر لوحي حامل للكمبيوتر اللوحي كابل الجهد 120 مم كابلات الطاقة( 290 مم) الاقطاب كابلات البحث (2 م) دليل المستخدم
